Quinoa is a miscellaneous grain that originated in the Americas and is mainly produced in Peru and Bolivia. Although its taste is inferior to common food crops such as rice and wheat, it is “the only fully nutritious plant certified by FAO”, “super food”, and ” With the support of many labels such as “Golden Grain”, “King of Vegetarian Food” and “Mother of Food”, it has become very popular in recent years.
Today I will talk about how to clean quinoa:
(1) Quinoa cleaning machine
working principle
The air screen cleaning machine consists of five parts: an ultra-low speed non-crushing elevator, an environmentally friendly dust collector, a closed rotary dust discharge valve, a vertical air screen, and a vibrating classification screen. The material enters the bulk grain box through the elevator and is evenly dispersed into the vertical air screen. The material separates light impurities under the action of wind. The light impurities are filtered by the cyclone dust collector and discharged from the rotary dust discharge valve. The remaining materials enter the screen box. Different specifications of precision punching screens are adjusted according to the external dimensions of the material to remove large and small impurities. At the same time, the finished product is divided into large, medium and small particles by increasing or decreasing the number of screen layers.
Product advantages
1. The original 2 and 3-layer turning plate allows you to press the handle when you don’t need to separate large pieces;
2. The whole machine is connected by bolts to avoid welding deformation;
3. The elevator has a unique design, ultra-low speed and no breakage;
4. It can be used movable or fixedly.
Scope of application
Suitable for screening and grading of various materials.
(2) Quinoa destoning machine
working principle
The blowing specific gravity destoner is based on the difference in the specific gravity of crops and stones in the material. By adjusting parameters such as wind pressure and amplitude, the stones with larger specific gravity sink to the bottom and move from low to high against the screen surface, while the crops with smaller specific gravity move from low to high. The suspension moves from high to low on the surface to achieve the purpose of separation.
Product advantages
1. Large output: Large countertop design greatly increases stone removal output;
2. High configuration: using pure imported sample wood, the table is not easy to deform and crack;
3. High configuration: The stone removal countertop adopts stainless steel woven mesh to extend the service life;
4. The stone outlet is equipped with a back-blowing function to effectively reduce the carry-out ratio of materials in the stone;
5. The rice metal parts are cut by imported laser to ensure accuracy, and the whole machine is connected with bolts to avoid welding deformation.
Scope of application
It can be adjusted by frequency and air volume, and is suitable for stone removal of different products such as small particle materials (millet, sesame), medium particle materials (mung beans, soybeans), large particle materials (kidney beans, broad beans). It is suitable for the selection of single-purpose materials, and can effectively remove heavier impurities such as stone (sand and gravel with a particle size similar to the material) in the material. In the grain processing process, it should be installed at the end of the screening process. Raw materials that have not removed large, small, and light impurities should not directly enter the machine to avoid affecting the stone removal effect.
(3) Quinoa grading sieve
working principle
Different specifications of precision punching screens are adjusted according to the external dimensions of the materials to classify the materials.
Product advantages
1. The original 2 and 3-layer turning plate allows you to press the handle when you don’t need to separate large pieces;
2. The whole machine has a compact structure, is easy to operate and clean, and can effectively prevent mixing;
3. The screens can be replaced at will to achieve the ideal screening effect.
Applicable materials
Suitable for grading various materials.
(4) Quinoa polishing machine
working principle
The polishing machine uses the principle of spiral transmission to transport materials. It removes dust and dirt adhered to the surface of various beans and grains through the friction of the canvas against the materials and the friction between the materials, and polishes and polishes the surface.
Product advantages
1. Special internal structure with remarkable polishing effect;
2. High-quality white canvas with low breakage rate;
3. While polishing, corn stalks and other debris can be removed;
4. Made of 304 stainless steel braided mesh, it has strong wear resistance and extends the service life of the equipment.
Applicable materials
This machine is suitable for polishing various beans and grains.
Post time: Jan-05-2024
